WALLTITE®

WALLTITE® Insulating Air Barrier
Improve energy efficiency by up to 40%


Insulation. Air barrier. Vapor barrier. Drainage plain. One product…one application. Fully-tested and field-proven.


Thanks to its 90% closed-cell content, the WALLTITE® system combines industry-leading air permeance ratings and a superior insulation R-value to make a significant contribution to building energy efficiency.


The WALLTITE® insulating air barrier system:

  • Eliminates uncontrolled air leakage
  • Improves occupant comfort, health and safety
  • Improves indoor environmental quality
  • Improves structural strength
  • Reduces condensation, moisture and mold problems
  • Conforms to any shape
  • Is approved by the Air Barrier Association of America (ABAA) to meet the mandated air barrier requirements of the Commercial Energy Codes of Massachusetts, Wisconsin and Michigan
  • Is installed only by ABAA approved applicators with third-party quality control inspection

Compare WALLTITE® with traditional systems


WALLTITE® Sheet goods: peel ‘n’ stick, torch-applied Open-Cell Foam
R-value

6.7

0.0

3.5

Air Permeability

Air leakage <0.001 L/s/m² @ 75 Pa at 1” thickness

Air barrier discontinuity allows leakage at poorly constructed joints

Air leakage 0.005 L/s/m² @ 75 Pa at 3.5” thickness

Absorbs Water

<4% v/v

Yes

>40% v/v

Allows Moisture Vapor In

No

Yes

Yes

Seamless Construction

Yes

Air barrier discontinuity allows leakage at poorly constructed joints

Yes

Adds Structural Strength

Yes – self-supporting, rigid, peak wind load resistance, fully adheres to wall system

No – supported by wall system, relies on adhesives

No – fully adheres to wall system, does not add structural strength

Installation

Fast – spray-applied, no fasteners, no gluing, no heat

Labor intensive – multi-step

Fast – spray-applied, no fasteners, no gluing, no heat
